Silicon Avalanche Diodes
Axial Leaded High Power Automotive Transient Voltage Suppressors
RoHS
SLD? Series
Package Outline Dimensions
Characteristics @25?C case temp (unless otherwise noted)
Part Number
Working
Breakover
Maximum
Clamping Max Peak
voltage
Voltage (bv) @It
leakage
Voltage
Pulse
Case Style P600
(Vr)
mi n max
It
current
(Ir) @ Vr
(Vcl) @ Ipp
Current
Ipp
UNI
BI
volts
volts
volts mA
μA
volts
A
SLD16U-017
SLD24U-017
SLD16-018
SLD24-018
16
24
18.0
25.0
22.0
30.0
1.0
1.0
10.0
10.0
28.6
36.0
76
61
1.0 (25.4)
MIN.
SLD10U-017
SLD10-018
3 x SLD 10U
10
30
11.8
35.4
13.0
39.0
5.0
5.0
10.0
10.0
19.0
45.0
115
100
in series
0.360 (9.1)
0.340 (8.6)
DIA.
0.052 (1.32)
0.048 (1.22)
DIA.
0.360 (9.1)
0.340 (8.6)
1.0 (25.4)
MIN.
Note 3. Using 100μS / 150mS pulse as defined by ISO7637/2 pulse #5.
Please note, U suffix denotes uni-directional.
Dimensions in inches and (millimeters)
306
w w w. l i t t e l f u s e . c o m
